196 1-800-452-1261
Stirrers, Magnetic
4'' x 4''
AP9804
Please contact us for step-by-step instructions regarding the replacement of
your Flinn stirrer or Flinn hot plate/stirrer ceramic tops.
7'' x 7''
AP9809
STIRRERS, MAGNETIC continued on next page.
DLAB EcoStir™ Magnetic Stirrer
EcoStir™ is affordable and lightweight! Features include:
• Maintenance free, brushless DC motor
• Rare earth magnets for strong stirring power
• Stepless speed regulation range of 300–2000 rpm
• Silent and vibration-free design
• PET top provides excellent chemical resistance.
• Shaft can be fitted with a pH sensor or sensors for other purposes.
Catalog No. Description Price/Each
AP9552 DLAB EcoStir™ Magnetic Stirrer $69.30
Mini Magnetic Stirrer
Inexpensive, yet very efficient. Stirring action speed is
adjustable from 100–1000 rpm, depending on the viscosity
of the medium you are stirring. The ABS plastic top is
easy to clean and can hold up to a 1-liter beaker. Do not
place hot materials on this top since it is plastic and will
melt. Dimensions: 12 cm L x 12 cm W x 4.6 cm H.
Catalog No. Description Price/Each
AP8578 Mini Magnetic Stirrer $134.00
DLAB FlatSpin™ Compact Magnetic Stirrer
With excellent stirring functionality, the ultra-thin,
compact design of the FlatSpin™ magnetic stirrer
takes up less bench space and makes storage easier.
Features include:
• Wide range of speed from 15–1500 rpm
• Automatic reverse rotation for excellent mixing
• PET top provides excellent chemical resistance
• Ultra silent operation, lightweight and vibration-free
Catalog No. Description Price/Each
AP9551 DLAB FlatSpin™ Compact Magnetic Stirrer $128.00
Flinn Mini Magnetic Stirrer
Our Flinn mini magnetic stirrer may be small but
is an enormous time-saver. All the features you
need in a magnetic stirrer are provided at an affordable price.
• Powerful enough to stir 1000 mL of liquid up to 2000 rpm.
• Stirring speed adjustable from 350-2000 rpm.
• ABS plastic outer shell and anti-slip foot pads.
• Splash-proof sealed components and
LED display screen
• Working diameter: 110 mm
• Maximum stirring capacity: 5,000 mL
• Includes mini-stir bar and AC/DC adapter.
Catalog No. Description Price/Each
AP8503 Flinn Mini Magnetic Stirrer $188.00
Flinn Magnetic Stirrer
With a very flat 7" x 7" stirring surface and
cast aluminum base, the Flinn Magnetic Stirrer
uses state-of-the-art ceramics to provide a
remarkable top surface. The ceramic material
offers high-impact strength, excellent chemical
resistance and a bright white color to enhance
solution visibility. Continuously variable stirring
speeds from 300 to 2000 rpm using a
maintenance-free brushless DC motor. Supplied with a PTFE-coated stirring bar.
Complete with three-wire grounded cord and plug. Replacement Ceramic Top is
available separately. 120 volts, 30 watts.
Catalog No. Description Price/Each
AP9803 Flinn Magnetic Stirrer $351.00
AP8215 Replacement Ceramic Top 177.00
7'' x 7''
AP9805
Flinn Magnetic Stirrers/
Hot Plates
Bright, white ceramic top material offers high-impact strength and chemical
resistance. Stirrer speed can be adjusted from 200 rpm to 2500 rpm. The heating
elements are embedded so there are no exposed heat sources. Unit will reach
maximum temperature (538 °C) within eight minutes. Power indicator lights are
provided for both stirring and/or heating. Includes a PTFE-coated stirring bar,
three-wire grounded cord and plug. Integral ring-stand holder accommodates 1/2"
diameter support rod.
• 4" x 4": 120 volts, 3.5 amps, 405 watts.
• 7" x 7": 120 volts, 9.2 amps, 1086 watts.
Catalog No. Description Size of Top Price/Each
AP9804 Flinn Magnetic Stirrer/Hot Plate 4" x 4" $483.40
AP9805 7" x 7" 560.00
AP8213 Replacement Ceramic Top 4" x 4" 150.00
AP8215 7" x 7" 177.00
4'' x 4''
AP9808
Flinn Digital Hot Plates/
Magnetic Stirrers
Quickly set the desired temperature using an LCD digital display, which indicates
the current operating temperature. Bright, white ceramic top offers high-impact
strength and chemical resistance. Heating elements are embedded so there are no
exposed heat sources. Reaches maximum temperature (540 °C) within 15 minutes.
Stirrer speed control can be adjusted from 300 to 2000 rpm using a maintenancefree
brushless DC motor. A “HOT” warning flashes if the work plate temperature is
above 50 °C even when turned off. Includes three-wire grounded cord and plug.
Catalog No. Description Size of Top Price/Each
AP9808 Flinn Digital Hot Plates/
Magnetic Stirrers
4" x 4" $540.00
AP9809 7" x 7" 635.00
AP8213 Replacement Ceramic Top 4" x 4" 150.00
AP8215 7" x 7" 177.00
Accessories for Flinn Digital Hot Plates
Catalog No. Description Price/Each
AP9878 Temperature Sensor, 230 mm $ 79.30
AP9879 Temperature Sensor, 230 mm, Glass-Coated 98.55
AP9880 Temperature Sensor, 100 mm 79.30
AP9882 Temperature Sensor and Support Clamp Set 105.00
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
